How to Choose SFP Module | FIBEYE
Single-mode and multi-mode fiber optic modules use with different types of fiber optic cables. Single-mode modules use a 9/125 micrometer diameter fiber optic cable and can transmit light at
Can optical modules with different colors be used
Optical module pull tab colors indicate fiber type, wavelength, transmission distance, and module function, serving as a quick visual guide for network engineers.Purpose of Pull Tab ColorsThe colored pull tab on an optical module is not merely decorative; it provides a visual coding system to quickly identify the module's specifications without removing it from the port. This helps technicians determine whether a module is single-mode or multi-mode, its wavelength, and its transmission distance, streamlining installation, maintenance, and troubleshooting in data centers and network environments .Common Color CodesWhile exact colors may vary slightly by vendor, industry standards generally follow these conventions:Black: Multimode fiber (MMF), typically 850nm wavelength, suitable for short-distance transmission (under 2 km)Blue: Single-mode fiber (SMF), 1310nm wavelength, medium-distance transmissionPurple: SMF, 1490nm wavelength, medium-distance transmissionYellow: SMF, 1550nm wavelength, long-distance transmission (40 km+)Green: SMF, 1550nm wavelength, extended reach (80 km+)Beige: Often used for 40G QSFP+ SR4 modules (850nm, up to 150m over MMF) For BIDI (Bi-Directional) modules, pull tab colors indicate specific wavelength pairs for transmit and receive signals over a single fiber. CWDM (Coarse Wavelength Division Multiplexing) modules use distinct colors for each wavelength channel, typically ranging from 1270nm to 1610nm .Practical ConsiderationsCross-verification: Always check the module label or datasheet to confirm exact wavelength and distance, as vendor-specific variations exist .Maintenance efficiency: Color coding allows rapid identification during network upgrades or fault replacement, reducing downtime.Inventory management: Helps organize modules in warehouses or data centers by fiber type and distance capability .SummaryUnderstanding optical module pull tab colors is essential for efficient network deployment and troubleshooting. By using color as a first reference, engineers can quickly distinguish between single-mode and multi-mode modules, identify transmission distances, and recognize specialized functions like BIDI or CWDM, while always confirming details with the module's label or official documentation .
