How are trapezoidal cable trays connected

Trapezoidal cable trays are connected using splice plates, bolted connections, or quick-connect systems to ensure stability, safety, and proper cable management.Step-by-Step Connection Process1. Prepare the Tray Ends Ensure the ends of the trapezoidal cable trays are clean, aligned, and free of burrs. Check that the tray height and width match the connecting section, typically 85 mm or 110 mm for standard RLVL trays .2. Choose the Connection MethodSplice Plates/Bolted Connections: Flat metal plates with pre-drilled holes are bolted to the ends of two tray sections. This method is strong, reliable, and suitable for straight runs or heavy cable loads .Quick Connect Systems: Snap, slide, or twist mechanisms allow fast assembly with minimal tools. Ideal for large projects or when speed is critical, though usually compatible with a single manufacturer's trays .Elbow or Junction Plates: L, T, or cross-shaped plates are used to join trays at angles or junctions, helping route cables around corners or splits .3. Align and Secure the Trays Position the trays so that the ends meet evenly. Insert the splice or junction plates and tighten bolts using appropriate tools such as spanners or torque wrenches. Ensure the connection is firm to prevent sagging or movement under load .4. Check Load and Support Install tray supports according to the tray's weight and load requirements. Center-hung supports or wall brackets should be spaced according to manufacturer guidelines, typically every 3–3.6 meters, with a maximum load per hanger around 318–340 kg .5. Maintain Cable Management Standards Ensure the minimum bend radius for cables is respected as they exit the tray. Use covers or side rails if required for safety, protection, or aesthetic purposes .6. Inspect and Test After installation, check all connections for tightness, alignment, and stability. Verify that the trays are level and that cables can be easily added or removed for maintenance .Tips for Best PracticesAlways follow IEC 61537:2006 and local building codes for cable tray installation .Use matching materials for trays and connectors to prevent corrosion. Aluminum trays, for example, resist atmospheric corrosion but should be joined with compatible fittings .Consider future maintenance: quick-connect systems allow easier modifications, while bolted connections provide maximum strength.Avoid overloading trays and maintain proper spacing to prevent cable damage or sagging .By following these steps and selecting the appropriate connection method, trapezoidal cable trays can be securely installed, ensuring long-term stability, safety, and efficient cable management.
